LS-WT30 Triple Wheel Tracker
LS-WT30 Triple Wheel Tracker is a wheel tracking machine for asphalt rutting tests for EN 12697-22, AASHTO T324 workflows. Built for high-throughput labs and field programs demanding repeatable results.
Independent Triple Stations
Three fully independent wheels allow for triple-capacity parallel testing, significantly reducing research lead times.
Linear Guide Rail System
Heavy-duty steel rails and linear bearings suppress mechanical resonance during triple-wheel operation.
7kW Thermal Compensation
High-power heating matrix with five internal channels ensures rapid equilibrium in oversized chambers.
Multithreaded Data Acquisition
Windows controller simultaneously processes three independent 7-point sampling streams in real-time.
Heavyweight Structural Chassis
1,120kg machine mass provides extreme mechanical stability for high-load rutting simulations.
Multi-Zone Thermal Monitoring
Four independent RS485 controllers maintain perfect temperature uniformity across the 2.5m wide workspace.
| Stations | 3 Independent Wheel Tracks |
| Drive System | Heavy-Duty Rail Steel + Linear Guides |
| Wheel Frequency | 26.5 passes/min |
| Heating Power | 7000W (5-Channel Airflow Matrix) |
| Temp Monitoring | 4 Independent Temperature Channels |
| Controller | 17-inch Industrial PC (Windows OS) |
| Wheel Load | Standard 0.7MPa (Optional 1.0MPa Heavy Duty) |
| Power | AC 380V, 7.0kW |
| Dimensions | 2550*1060*1500mm |
| Weight | 1120kg (Gross: 1245kg) |
Application & Selection Guide
Asphalt rutting and wheel tracking performance testing
LS-WT30 Triple Wheel Tracker is an asphalt testing machine for rutting resistance and wheel tracking evaluation under EN 12697-22, AASHTO T324. It helps pavement laboratories compare asphalt mixture deformation under controlled wheel load, temperature, and wet or dry test conditions.
What is LS-WT30 Triple Wheel Tracker used for?
LS-WT30 Triple Wheel Tracker is used for asphalt rutting workflows in civil engineering materials laboratories, quality control labs, research programs, and construction material acceptance testing.
Which standards does LS-WT30 support?
LS-WT30 supports EN 12697-22, AASHTO T324. Lithostek can also configure reporting fields, accessories, and calibration documents around local project or laboratory requirements.
Can Lithostek configure LS-WT30 for my laboratory?
Yes. Lithostek application engineers can review specimen format, target standards, throughput, power supply, data output, and training requirements before quoting a suitable configuration.
